Centre for Internet of Things Anna University

High End Equipment

Sample
Pulsed Laser System
Splitlight compact 100
  • Company : M/s Innolas Laser, Germany
  • Active Medium : Nd: YAG
  • Wavelength : 1064nm
  • Max Energy : 100mJ
  • Pulse Width : 6ns
  • Beam Diameter : 5mm
Sample
Q-switched DPSS lasers
Splitlight compact 100
  • Company : M/s Optogama, Germany
  • Active Medium : Nd: YAG
  • Wavelength : 1064nm
  • Max Energy : 1mJ
  • Pulse Width : 6ns
  • Beam Diameter : 3mm @ 1m
Sample
Spectrometer
Kymera 193i
  • Andor- oxford instruments
  • Resolution : 1nm
  • Grating: interchangeable ( 800 G/ mm and 1200 G/mm)
  • Focal Length : 193mm
Sample
Delay Generator
Delay Generator
  • Delay Output Channels : 4 nos
  • Resolution : 5ps
  • Wavelength : 1064nm
  • Max delay : 2000 s
  • External Trigger : Rising edge or falling edge
  • Interface : Ethernet, GPIB ad RS 232
Sample
Photo Multiplier Tube
Multiplier Tube
  • PMT type : Multialkali
  • Spectral response : 185 -900 nm
  • Photocathode active area : 3.7 mm X 13.0 mm
  • Rise and fall time : 1.4 ns
  • Settling time : 10 s
Sample
Server
Lenovo
  • Model : SR650
  • Processor : 16C, 2.1 GHz
  • RAM :16 GB HDD RAM (4 Nos)
  • HDD : 1.2 TB (3 Nos)
Sample
Hot Air Oven
Double Wall Chamber
  • Maximum temperature 210˚C.
  • Continues operation 200˚C.
  • Accuracy ±1˚C
  • Material : Cold rolled Mild Steel with mirror powder coating.
  • Fan for uniform heating.
  • Digital on / off controller Accuracy of ±1˚C
Sample
Pellet Making Setup
Lenovo
  • Capacity : 5 Ton
  • Loading type : Hydraulic
  • Travel of Ram : 15 cm
  • Pressure gauge : External
  • Cast iron : 30mm die set

Embedded Boards

Machine Learning Kit - Arduino Tiny
  • Nano 33 BLE Sense Board
  • image/ video capture sensor
  • Tiny Machine Learning Shield
  • USB A to Micro USB Cable
AI board for Embedded Artificial Intelligence -- Beagle Bone
  • TI AM5729 Dual-Core ARMCortex-A15 processor running at 1.5GHz
  • Memory: 1GB RAM and 16GB on-board eMMC Flash
  • Connectivity: Gigabit Ethernet, 2.4/5GHz WiFi, and Bluetooth
Micro Python pyboard with headers
  • STM32F405RG microcontroller
  • 168 MHz Cortex M4 CPU with hardware floating point
  • 192KiB RAM
  • 24 GPIO plus LED and switch GPIO available on bottom row
DEVELOPER KIT -- JETSON XAVIER NX
  • GPU: 384-core NVIDIA Volta™ GPU with 48 Tensor Cores
  • CPU: 6-core NVIDIA Carmel ARM®v8.2 64-bit CPU 6 MB L2+4 MB L3
  • Memory: 8 GB 128-bit LPDDR4x 59.7GB/s
Development board - Galileo board
  • 86-bit Intel GALILEO GEN 2 development board
  • Intel X1000 chip quark system
  • Interface Type: Ethernet, I2C, SPI, UART, USB
  • Operating Supply Voltage: 7 V to 15 V
Processor board -- Raspberry Pi Zero
  • 1GHz single-core CPU
  • 512MB RAM
  • Mini HDMI port
  • Micro USB OTG port
  • Micro USB power
Mega board -- Arduino
  • Microcontroller: ATmega2560
  • Operating Voltage: 5V
  • Input Voltage: 7-12V
  • Input Voltage: 7-12V
  • Clock Speed: 16 MHz
WIFI and Bluetooth -- ESP32 Development Board
  • With support LWIP Protocol and Free RTOS
  • Supporting three modes: Access point, Station mode, and Access point + Station mode
  • Includes CP2102 USB-UART bridge
Wave share 10.1 Inch Capacitive HDMI LCD
  • Display (B) with Case 1280x800
  • IPS screen,1280 x 800 hardware resolution
  • Toughened glass capacitive touch panel, 6H hardness
  • HDMI interface for displaying, USB interface for touch control
  • Supports 5-level backlight adjustment
Processor board -- Raspberry pi 4b (8GB RAM)
  • Quad-Core 64-bit Broadcom 2711, Cortex A72 Processor
  • WLAN 802.11 b/g/n/ac (2.4 + 5.0 GHz)
  • LAN RJ45 10/100/1000 Mbit (Gigabit LAN over USB 3.0)
  • Operating Power 5V (or) 3A via USB Type-C port
AURIX TC399-KIT - Infineon’s
  • TC399 AURIX™ TC3xx Controller in LFBGA-516 Package
  • Crystal 20MHz (default) or External Clock
  • Asynchronous SRAM upto 2MB
  • Synchronous SRAM upto 4MB
